Mosfet 600v

Opto MOSFET relay for High Voltage Applications

Mosfet

MOSFET N-CH 600V 4A IPAK: N-Channel: MOSFET (Metal Oxide) 600V: 4A (Tc) TO-251-3 Short Leads, IPak, TO-251AA: STD3NK60Z-1: MOSFET N-CH 600V 2.4A IPAK: N-Channel: MOSFET (Metal Oxide) 600V: 2.4A (Tc) TO-251-3 Short Leads, IPak, TO-251AA: STL16N65M2: MOSFET N-CH 650V 7.5A POWERFLAT: N-Channel: MOSFET (Metal Oxide) 650V: 7.5A (Tc) 8-PowerVDFN. Datasheet: Power MOSFET, N-Channel, 600 V, 2.0 Ω Rev.

Bright TOWARD achieves a higher level of power handling capability using LED triggered D-MOSFET technology. Compared to traditional mechanical relays, Opto MOSFET relays provide great benefits, including reducing real-estate of PCB – small form factor, longer life as semiconductor, and high-speed switching -quick response and performance. Opto MOSFET relay for high voltage applications in Industrial, Robotics, Security, and a broad range of applications. The Control line is optically isolated from the high voltage signal line. Therefore, these products give design flexibility in high power applications and ensure great dielectric strength between input and output signals.

The much higher voltage required? Bright TOWARD Industrial Co., Ltd., released Silicon Carbide (SiC) products for high current and high voltage applications. Please visit out SiC page for more detail.

38 Series / 38-2 Series Opto MOSFET relay

Features

  • 60 to 80mA / 600V Load (38 Series)
  • 1500Vrms I/O Breakdown Voltage (38 Series)
  • 120mA / 650V Load (38-2 Series)
  • 3750Vrms I/O Breakdown Voltage (38-2 Series)
  • for industrial control, robotics, security, transportation equipment, instrumentation, meters, and aerospace/defense applications
Product NameContact FormLoad Voltage (Max)Operation LED Current (Max)Load Current (Max)On-Resistance (Typ)Output Capacitance (Typ)Off-State Leakage Current (Max)I/O Breakdown VoltageDevice PackagePackaging
AA381FormA600V3.0mA80mA40 Ohm47pF1.0uA3750VrmsDIP6Stick
AA38-H1FromA600V3.0mA80mA40 Ohm47pF1.0uA5000VrmsDIP6Stick
AA38F1FormA600V3.0mA80mA40 Ohm47pF1.0uA3750VrmsSMD6Stick/Tape
AA38F-H1FormA600V3.0mA80mA40 Ohm47pF1.0uA5000VrmsSMD6Stick/Tape
AB381FormA600V3.0mA80mA40 Ohm47pF1.0uA3750VrmsDIP4Stick
AB38-H1FormA600V3.0mA80mA40 Ohm47pF1.0uF5000VrmsDIP4Stick
AB38F1FormA600V3.0mA80mA40 Ohm47pF1.0uF3750VrmsSMD4Stick/Tape
AB38F-H1FormA600V3.0mA80mA40 Ohm47pF1.0uA5000VrmsSMD4Stick/Tape
AB38S1FormA600V3.0mA70mA40 Ohm47pF1.0uA1500VrmsSOP4Stick/Tape
AB38S-H1FormA600V3.0mA70mA40 Ohm47pF1.0uA3750VrmsSOP4Stick/Tape
AC382FormA600V3.0mA70mA40 Ohm47pF1.0uA3750VrmsDIP8Stick
AC38-H2FormA600V3.0mA70mA40 Ohm47pF1.0uA5000VrmsDIP8Stick
AC38F2FormA600V3.0mA70mA40 Ohm47pF1.0uA3750VrmsSMD8Stick/Tape
AC38F-H2FormA600V3.0mA70mA40 Ohm47pF1.0uA5000VrmsSMD8Stick/Tape
AC38S2FormA600V3.0mA60mA40 Ohm47pF1.0uA1500VrmsSOP8Stick/Tape
AC38S-H2FormA600V3.0mA60mA40 Ohm47pF1.0uA3750VrmsSOP8Stick/Tape
AA38-21FormA650V5.0mA120mA20 Ohm110pF1.0uA3750VrmsDIP6Stick
AA38-2H1FormA650V5.0mA120mA20 Ohm110pF1.0uA5000VrmsDIP6Stick
AA38F-21FormA650V5.0mA120mA20 Ohm110pF1.0uA3750VrmsSMD6Stick/Tape
AA38F-2H1FormA650V5.0mA120mA20 Ohm110pF1.0uA5000VrmsSMD6Stick/Tape

38-2 Series Data Sheet

Mosfet 600v 40a

Mosfet

Please contact us for 38-2 Series Data Sheet

High Power Mosfet

39 Series Opto MOSFET relay

Features

  • 50mA /1000V Load
  • 3750Vrms I/O Breakdown Voltage
  • for industrial control, robotics, security, transportation equipment, instrumentation, meters, and aerospace/defense applications
Product NameContact FormLoad Voltage (Max)Operation LED Current (Max)Load Current (Max)On-Resistance (Typ)Output Capacitance (Typ)Off-State Leakage Current (Max)I/O Breakdown VoltageDevice PackagePackaging
AA391FormA1000V5.0mA60mA100 Ohm144pF10uA3750VrmsDIP6Stick
AA39-H1FormA1000V5.0mA60mA100 Ohm144pF10uA5000VrmsDIP6Stick
AA39F1FormA1000V5.0mA60mA100 Ohm144pF10uA3750VrmsSMD6Stick/Tape
AA39F-H1FormA1000V5.0mA60mA100 Ohm144pF10uA5000VrmsSMD6Stick/Tape
Mosfet 600vMosfet 600v

39 Series Data Sheet

Please contact us for 39 Series Data Sheet

40 Series Opto MOSFET relay

High current mosfet

Features

  • 45mA / 1500V Load
  • 3750Vrms I/O Breakdown Voltage
  • for industrial control, robotics, security, transportation equipment, instrumentation, meters, and aerospace/defense applications
Product NameContact FormLoad Voltage (Max)Operation LED Current (Max)Load Current (Max)On-Resistance (Typ)Output Capacitance (Typ)Off-State Leakage Current (Max)I/O Breakdown VoltageDevice PackagePackaging
AA401FormA1500V5.0mA45mA180 Ohm83pF10uA3750VrmsDIP6Stick/Tape
AA40-H1FormA1500V5.0mA45mA180 Ohm83pF10uA5000VrmsDIP6Stick/Tape
AA40F1FormA1500V5.0mA45mA180 Ohm83pF10uA3750VrmsSMD6Stick/Tape
AA40F-H1FormA1500V5.0mA45mA180 Ohm83pF10uA5000VrmsSMD6Stick/Tape

This 2.5kW CCM full-bridge PFC evaluation board utilizes the advantages of Infineon’s CoolGaN™ technology to boost system efficiency above 99 percent for efficiency-critical applications such as server power supplies or telecom rectifiers. The board features CoolGaN™ 600V e-mode HEMTs, CoolMOS™ C7 Gold superjunction MOSFET and EiceDRIVER™ gate driver ICs.

Mosfet 600v

The input voltage range of the board is between 90 to 265VAC, while the output voltage is 390VDC. All power components are surface mount devices (SMD), enabling faster and cheaper assembly process.
